Automatic sachet settle machine sachet collecting machine 100 sachets counting machine
RT-HX300 Sachet counting and collecting machine is composed of silo (with conveying function at the bottom),.
Wide application range, food, medicine, cosmetics, skin care products and dairy products and other industries, a wide range of flexible, easy to replace, intelligent system control, modular design, technological innovation, simple operation, small footprint, cost saving. Diversified form of material.
Machine dimensions (standard) : 2500x1300x1900(mm) (length x width x height)
2, machine weight: 800Kg
3, input voltage: three-phase 220V
4, power supply: 8.0KW
5, power cable cross-sectional area: >6mm²
6, frequency: 50Hz
7, working environment temperature: -10~65°C
8, size range: length: ≤200mm width: ≤120mm
9, feeding speed: up to100 sachets/min (related to material size and characteristics)
| Item | Name | Brand | Note |
| Electrical fittings | Touch screen | INOVANCE/BECKHOFF | China/Germany |
| Motion control | INOVANCE/BECKHOFF | China/Germany |
| Sensor | SICK/KEYENCE | Germany/Japan |
| Low voltage electrical | Schneider/OMRON | France/Japan |
| Pneumatic fittings | Cylinder | FESTO/SMC | Germany/Japan |
| Air valve | FESTO/SMC | Germany/Japan |
| The part in contact with materials is SUS304, part of the frame is carbon steel epoxy resin paint, the outer cover is 304 stainless steel plate, and the front door of the equipment is plexiglass. |
Others terms:
1. The price includes the necessary accessories.
2. Machine Packing: Wooden Box
3. Warranty & Services
a. We provide overseas installation and training of machine operation. All fees including visa, transportation, accommodation will be afforded by buyer, what's more, USD 100 installation fee should be paid.
b. Warranty Period: 12 months
c. We provide the replacement parts for free due to quality problems under proper operation within warranty period
d. After warranty period, we will charge the replacement parts at cost price.
e. We provide lifetime support for all the machines.
4. Delivery Time: 20 work days after the deposit
5. Payment Terms: 40% advanced by T/T, the balance should be paid off by the shipment.
6. Valid Time of the Quote: 1 months after the issuing date
